Stealth Cam STC-I890 Rogue - Manual (Page 27)

STC-I890
www.stealthcam.net Toll Free 877-269-8490 27
Testing the Camera Coverage Area

After mounting the camera, open front housing and slide the power
toggle switch to TEST.

Close the front housing.

Walk around in the front of the camera to see if you have mounted
the camera in the proper position. A green indicator light on the
front will blink when you have intruded the coverage area.

Adjust the camera position as needed, and repeat testing until the
desired coverage area is achieved.

When you have completed testing the coverage area, open the
front housing and slide the power toggle switch from TEST to ON
position. This will exit the test mode. The camera will then enter
one minute count down mode. The front green LED indicator will
blink giving you one minute to leave the coverage area. Then the
camera will enter PIR detection mode.
