Charvel® r&d guitar specification summary

Charvel® R&D Guitar Specification Summary
Model:
San Dimas®, Style 1 2H (Rev 2)
Series:
U.S.A. Production Model
Neck-thru or Bolt-on
Bolt-on
Description
San Dimas® Style 1
Body Wood
Alder (no veneer)
Body Binding
No
Scallop Heel
No
Scallop Horn
No
B
O
D
Y
Other
Neck Description
Charvel USA San
Dimas®
Reg./Reverse Headstock
Regular
Neck/Centerblock Wood
1 pc Maple -
Quartersawn
Fingerboard Wood
n/a
Inlay
Dots
Nut Width
42.86 mm [1 11/16
inch]
Butt Width
57.15 mm [2 ¼ inch]
Scale Length
25.5"
# of Frets
22
Fret Wire
Dunlop® Jumbo 6100
(or SBB equivalent)
Fret Scallop
No
Neck Binding
No
Head Binding
No
N
E
C
K
Neck Backshape
Charvel USA San
Dimas®
Other
12”-16” Compound
Radius
Bridge
Floyd Rose®
Recessed/Pullback
No
Nut
Floyd Rose R3
Strap Button
Dunlop
Jack Location
Side
Jack Type
Oval
Tuners
Grover® Mini
Rotomatic
Parts Color
Black
Knobs
Black (knurled)
Pickguard
No
Rear Control
Yes – San Dimas®
Battery Cavity
No
P
A
R
T
S
Other
Pickup Route
2H
Active Electronics
No
Bezels
Yes
Covered Pickup
No
Bridge Pickup
Seymour Duncan® TB4
Middle Pickup
Neck Pickup
Seymour Duncan SH1N
Volume
One
Tone
No
Other Knobs
Pickup Selector
3 Way Toggle
Position 1
Bridge
Position 2
Bridge & Neck
Position 3
Neck
Position 4
Position 5
Other Switches
C
O
N
T
R
O
L
S
Placement Instructions
Recessed back plates – (black)
Standard Colors
Black
Rotation Colors
#1 Candy Apple Red, #2 Candy Blue, #3 Slime Green
Neck Finish
Gunstock oil
Painted Pickups
No
Artwork or Color Sample
Headstock Color
Natural – stain matte
on front
Logo Type
Charvel
Logo Color
Black
Other
F
IN
IS
H
Case
Charvel padded gig bag
©2008 JCMI, Inc. All rights reserved. Specifications subject to change without notice.
The unique Stratocaster® headstock and body designs are trademarks of FMIC under license to JCMI, Inc.
