Ported Enclosure
Box Volume *2.0 Cu Ft.
Port Frequency (Fb) 31Hz
Port Diameter 4 Inches
Port Length 14.33 Inches
* Box is given as internal air volume including port and driver displacement.
EL1208 RECOMMENDED ENCLOSURES
Please Note: Our suggested box volumes are given as internal air requirements
Sealed Enclosure
Box Volume * 0.83 Cu Ft.
* Box is given as internal air volume including driver
Displacement.
EL1208 Amplitude Response (dB/Hz) EL1208 Amplitude Response (dB/Hz) Sealed Enclosure Sealed Enclosure
5 Hz 10 50 100 100 500 500 1000 1000
0 dB
Frequency Frequency
6
12
-6
-12
-18
-24
F3 = 56 F3 = 56
EL1208 Amplitude Response (dB/Hz) EL1208 Amplitude Response (dB/Hz) Ported Enclosure Ported Enclosure
5 Hz 10 50 100 500 1000 1000
0 dB
Frequency Frequency
6
12
-6
-12 -12
-18
-24
F3 = 36 F3 = 36
