LaserLyte LT-120 - Large Rez Size - Manual (Page 2)

Center Mass™ Universal
Shotgun Laser Trainer
Batteries: (3) A76
Unscrew Battery cap.
Remove batteries.
Install new batteries.
Tighten battery cap. 1
1
2
2
3
4
DANGER
LASER LIGHT
AVOID DIRECT EYE EXPOSURE
POWER OUTPUT < 5mw
WAVELENGTH 630-670mm
CLASS IIIa PRODUCT
LT-120
12 Gauge Adapter 20 Gauge Adapter
WARRANTY:
Three Year Limited
Warranty.
Installation:
• WARNING! YOUR BATTERIES WILL GO DEAD!
REMOVE THE BATTERIES WHEN NOT IN USE!
• THE SOUND ACTIVATED SWITCH IS ALWAYS
LISTENING.
• THE BATTERIES ARE ALREADY INSTALLED,
YOU MUST REMOVE A PIECE OF PLASTIC
INSULATOR BEFORE OPERATION.
• LASERLYTE STRONGLY RECOMMENDS THE USE
OF SNAP CAPS.
1
1
2
2
3
4
6
5
5
6
STOP
UNLOAD YOUR FIREARM!
Insert screw through adapter and thread
into taper of trainer.
Tighten down screw until snug.
Gently press the trainer into the barrel of
the shotgun.
Ready your shotgun and pull trigger to fire
red laser pattern.
When removing from your shotgun, pull
straight out! Do not twist! Ensure all parts
are out of barrel.
UNLOAD YOUR FIREARM!
3
4
Correct removal
+ + +
3
4
+ + +
®
