CBT Sight-in Steps
UNLOAD YOUR FIREARM! ALWAYS POINT IN A SAFE
DIRECTION.
Insert laser into the chamber of the firearm. Do not pull
the trigger with the bore tool in your chamber.
Close bolt and laser will turn on.
Shine laser dot out 25-30 yards/meters.
Adjust cross hairs directly on top of the laser dot.
REMOVE BORE TOOL!
Go to shooting range and fire first 100 yard/meter shot.
Make final adjustments.
Changing batteries
The CBT takes three 393 batteries
Unscrew the back of the laser located near the rim of
the cartridge.
Take out old batteries and insert new batteries with
positive (+) facing out.
Screw the cap back on all the way.
Changement de piles
Le cartouche d’alignement a besoin de 3 piles 393
Dévissez le dos du laser qui est situé au bord de
la cartouche.
Enlevez les vieilles piles et insérez les nouvelles piles
du coté positif (+) faisant face.
Revissez le couvercle complètement.
Use with Sleeves
Insert the .223 laser bore sighter into the additional
caliber sleeves.
Follow the CBT Sight-in Steps.
2
