TLB-1 Target Usage:
To display your shot:
•Firing the red laser dot in the Display circle
will illuminate your shots on the target.
To reset your shots:
•Firing the red laser dot at the Reset circle
will clear the target. Turning the target OFF
and then ON will also clear the target.
Position target facing shooter
. Be sure the target is in proper lighting
conditions. A strong light source may affect the TLB-1’s ability to register “hits”.
Move switch to ON position.
Fire laser at Reset Circle twice to activate target.
With any LaserLyte® Laser Trainer fire the red laser dot in the target area.
