CBT Sight-in Steps
UNLOAD YOUR FIREARM! ALWAYS POINT IN A SAFE
DIRECTION.
Insert laser into the chamber of the firearm. Do not pull
the trigger with the bore tool in your chamber.
Close bolt and laser will turn on.
Shine laser dot out 25-30 yards.
Adjust cross hairs directly on top of the laser dot.
REMOVE BORE TOOL!
Go to shooting range and fire first 100 yard shot.
Make final adjustments.
Changing batteries
The CBT takes one CR2 Lithium battery
Unscrew the back of the laser located near the rim of
the cartridge.
Take out old battery and insert new battery with
positive (+) facing out.
Screw the cap back on all the way.
2
3
4
5
6
1
7
2
3
4
5
6
1
7
1
2
3
1
2
3
.5<3721<7(
&$575,'*(%25(722/
%0*
.
25-30 Yards
100 Yards
Laser Dot
+
-
CBT Sight-in Steps
UNLOAD YOUR FIREARM! ALWAYS POINT IN A SAFE
DIRECTION.
Insert laser into the chamber of the firearm. Do not pull
the trigger with the bore tool in your chamber.
Close bolt and laser will turn on.
Shine laser dot out 25-30 yards.
Adjust cross hairs directly on top of the laser dot.
REMOVE BORE TOOL!
Go to shooting range and fire first 100 yard shot.
Make final adjustments.
Changing batteries
The CBT takes one CR2 Lithium battery
Unscrew the back of the laser located near the rim of
the cartridge.
Take out old battery and insert new battery with
positive (+) facing out.
Screw the cap back on all the way.
2
3
4
5
6
1
7
2
3
4
5
6
1
7
1
2
3
1
2
3
.5<3721<7(
&$575,'*(%25(722/
%0*
.
25-30 Yards
100 Yards
Laser Dot
+
-
