Ballast board removal ballast board installation – Kino Flo MG3R Ballast Board User Manual
Page 3
Ballast Board Removal
Ballast Board Installation
1) Remove ten (10) cover screws.
4) Install new ballast board and
three (3) nuts
2) ) Remove AC input, lamp output
connector and HO/Std connector.
5) Install AC input, lamp output
connector and HO/Std connector.
3) Remove three (3) nuts on each
board.
6) Install ten (10) cover screws.
3
Mega 4Bank Ballast (BAL-410-M120)
is shown for illustration purposes.
