3

DIM-5 Dimmer Operation

Insert one end of cable into receptacle

on the

DIM-5.

No batteries are required to operate

the

DIM-5; the power is drawn from the

Fixture.

BarFly 450, 400D/200D

Insert other end of the

DIM-5 cable into

the receptacle marked: REMOTE DIM.

The

DIM-5 dimmer will automatically

override the onboard dimmer.

Diva-Lite 401/201, 400U, 400/200

Insert other end of the

DIM-5 cable into

the receptacle marked: REMOTE DIM.

The

DIM-5 dimmer will automatically

override the onboard dimmer.

Tegra 450, 400

Insert other end of the

DIM-5 cable into

the receptacle marked:

REMOTE DIM.

The

DIM-5 dimmer will automatically

override the onboard dimmer.
