Ballast Board Removal
Ballast Board Installation
1) Remove eight (8) cover screws.
4) Install new ballast board and
three (3) nuts.
2) Remove AC input and lamp
output connector.
5) Install AC input and lamp output
connector.
3) Remove three (3) nuts on each
board and remove ballast board.
6) Install eight (8) cover screws.
2
Foto-Flo 400 Ballast (BAL-422-120)
is shown for illustration purposes.
