AutoHybrid Auto-Answer Hybrid
4
Connecting your AutoHybrid
1. Use the supplied RJ-11 cable to
connect the jack on your
AutoHybrid to an analog phone line
wall jack.
2. Connect the audio you wish to send
down the phone line to the XLR
jack on your AutoHybrid.
3. Connect the XLR jack
to a line level input on your audio
equipment. The Caller output
contains audio coming from the
phone line. This audio signal will
contain the caller's voice and any
audio you send into the phone line
at approximately 20 dB less than
your transmit level.
Connecting Your AutoHybrid
Note: When you drop a call, any audio
delivered to the Send jack of AutoHybrid
will still appear on the Caller output jack.
AutoHybrid does not mute your Send
audio when the phone line is On Hook.
4. Connect an auxiliary telephone to
the jack to dial calls. After
connecting a call, press the
Button> on the AutoHybrid and you
may then hang up the telephone.
When you are finished with the call,
press the to release
the phone line (place the line
on hook).
