256884 FHEX Instruction Sheet
Figure 2. Typical Horn Installation Wiring.
WARNING
Unauthorized repair/servicing of the unit may result in degra-
dation of performance and/or property damage, serious
injury, or death to you or others. If a malfunctioning unit is
encountered, do not attempt any field repair/retrofit of parts.
F. SERVICE.
The factory will service your equipment or provide technical
assistance with any problem that cannot be handled locally with
satisfaction or promptness.
If any unit is returned to factory for repair, it can be accepted only
if we are notified by mail or phone in advance of its arrival. Such notice
should clearly indicate service requested and give all pertinent informa-
tion regarding nature of problem and, if possible, its cause.
Communications and shipments should be addressed to:
Technical Service Department
Commercial Products Group
2519 - 4th Avenue
Moline, IL 61265
800.521.8219 • FAX 800.225.4109
Vibratone is a registered trademark of Federal Signal
Corporation.
RED
BLK
RED (+)
( - )
24 VDC
HORN POWER
END OF THE LINE DEVICE
RECOMMENDED BY
CONTROL UNIT SUPPLIER
VIBRATORY
HORN
MODEL
FHEX
BLK
RED
BLK
RED
BLK
290A2627-23
