Hanns.G HP221 - Manual (Page 24)

User’s Manual
APPENDIX
SPECIFICATIONS
Driving system TFT Color LCD
Size 22" LCD Panel
Pixel pitch 0.282mm(H) x 0.282mm(V)
H-Frequency 24KHz –83KHz
Video
V-Frequency 56 – 75Hz
Display Colors 16.7M Colors
Max. Resolution 1680 x 1050 @60Hz
Plug & Play VESA DDC2B TM , DPMS
ON Mode 55W (Typical)
Power Saving Mode ≤1 W Power consumption
OFF Mode ≤1 W
Audio output Rated Power 1.5 W rms (Per channel)
Input Terminal
VGA
DVI (Dual-Input Model)
Maximum Screen Size
Hor. : 473.8mm
Ver. : 296.1mm
Power Source 100~240VAC,50±3Hz,60±3Hz
Environmental
Considerations
Operating Temp: 0° to 40°C
Storage Temp.: -20° to 55°C
Operating Humidity: 20% to 80%
Dimensions
510 (W) x 464(H) x 203(D) mm
20 ”(W)×18.3 ”(H)×8.0 ”(D)
Weight (NW) 5.5kg (12.1 lb)
*** The above specification is subject to actual product specification and is subject to change
without prior notice.
NOTES:
The Maximum Resolution will depends on the display card supporting. Related issue can refer to
www.hannsg.com FAQ section.
24
