Specifications
Frequency Response 44Hz – 25kHz (±3dB)
Recommended Amplifier 15 – 200 watts
Sensitivity 89dB [2.8v at 1m]
Nominal Impedance 8 ohms
Crossover Frequency 2,800Hz
Woofer Dual 61/2” (165mm) copolymer
DCD with Phase Plugs
MBOS Dual 7” (178mm)
(Maximum Bass Output System) passive radiators plus
MBOS Rear Port
Tweeter 1” (25mm) Kortec®
Soft Dome
Dimensions (H x W x D) 433/16 x 117/8 x 99/16”
(1096 x 302 x 242 mm)
Weight 28.2 lbs (12.9kg)
Finish black lacquer
300 Jubilee Drive, Peabody, MA 01960 bostonacoustics.com
© 2009 All rights reserved. Boston, Boston Acoustics, the B/A ellipse symbol, and MagnaGuard are registered trademarks, and Play Smart are trademarks of Boston Acoustics, Inc.
Specifications
VS 240 VS 260 VS 224 VS 325C VS 344 VS 336
Frequency Range (±3dB) 70Hz – 30kHz 45Hz – 30kHz 78Hz – 30kHz 65Hz – 30kHz 42Hz – 30kHz 35Hz – 30kHz
Recommended Amplifier 10 – 100 Watts 10 – 250 Watts 10 – 200 Watts 10 – 250 Watts 10 – 250 Watts 10 – 400 Watts
Sensitivity 86 dB SPL/2.8V/m 87 dB SPL/2.8V/m 87 dB SPL/2.8V/m 90 dB SPL/2.8V/m 87 dB SPL/2.8V/m 87 dB SPL/2.8V/m
Nominal Impedance 8 ohms 8 ohms 8 ohms 8 ohms 8 ohms 8 ohms
Crossover Frequency 2,000 Hz 1,900 Hz 1,900 Hz 350 / 2,400 Hz 300 / 2,500 Hz 250 / 2,500 Hz
Bass Driver 4 1 /
2
” (114mm) 6 1 /
2
” (165mm) Dual 4 1 /
2
” (114mm) Dual 5 1 /
4
” (133mm) Quadruple 4 1 /
2
” (114mm) Triple 6 1 /
2
” (165mm)
Midrange Driver — — — 3” (76 mm) 4 1 /
2
” (114mm) 4 1 /
2
” (114mm)
High-Frequency Driver 1” (25mm) 1” (25mm) 1” (25mm) 1” (25mm) 1” (25mm) 1” (25mm)
Super Wide Bandwidth Super Wide Bandwidth Super Wide Bandwidth Super Wide Bandwidth Super Wide Bandwidth Super Wide Bandwidth
Dimensions (H x W x D) 9 7 /
16
x 5 7 /
8
x 6 3 /
8
” 14 1 /
2
x 9 x 10 1 /
4
” 25 x 5 3 /
4
x 3 1 /
4
” 7 1 /
8
x 28 3 /
16
x 6 5 /
16
” 44x5 3 /
8
x8 3 /
8
” 46 1 /
16
x 9 7 /
8
x 12 13 /
16
”
(240 x 150 x 162mm) (365 x 225 x 260mm) (632 x 148 x 96mm) (181 x 716 x 161mm) (1117 x 148 x 161mm) (1170 x 250 x 325mm)
Weight: 6.3 lbs (2.9Kg) 9 lbs (4.1Kg) 18 lbs (8.2Kg) 25.9 lbs (11.78 Kg) 32.2 lbs (16.5 Kg) 66.3 lbs (30.12 Kg)
Specifications
VPS 210
Frequency Range 22 Hz – 150 Hz, ±3dB
Amplifier Power Class D, 500 watt RMS (1,800 watt peak)
Bass Driver 10” (254mm) Long throw OCCM woofer
with 3” voice coil
Passive Radiator 10” (254mm) OCCM passive radiator
Dimensions (H x W x D) 15 x 13 7 /
8
x 21 1 /
4
”
(381 x 353 x 540mm)
Weight: 62 lbs (28.2kg)
Boston Acoustics continually strives to update and improve its products.
The specifications and construction details are subject to change without notice.
Available end panel finishes
Cherry gloss black enclosure with gloss cherry end panels and black grille
Black gloss black enclosure with gloss black end panels and black grille
