F U S I O N ™ 1 0 0 0 L 9 " & 1 2 " L A M I N AT O R S
5
technical specifications
Electrical 9”: 120V AC / 60Hz /
1.9A / 230W
12”: 120V AC / 60Hz /
2.7A / 330W
Machine Dimensions 9”: 14.57x4.23x3.15 inch
(370x107.5x80mm)
12”: 18.3x4.29x3.18 inch
(465x109x81mm)
Machine Weight 9”: 2.84lbs (1.29kg)
12”: 3.55lbs (1.61kg)
Maximum Pouch Width 9”: 9.5 inch (241mm)
12”: 12.0 inch (303mm)
Maximum Pouch
Thickness
9”: 3 mil (up to legal) (75mic)
9”: 3 mil (up to photo 4x6
inch) (125mic)
12”: 5 mil (up to photo 4x6
inch) (125mic)
Maximum Thru-put
Thickness
0.7mm
Warm-Up Time Approximately 5 minutes
Speed 13 inches (330mm)
per minute
service
Do not attempt to service or repair the pouch laminator yourself. Unplug the unit and contact an
authorized Swingline GBC service representative for any required repairs.
points to note
• Use this unit only for its intended use of laminating documents
• Do not laminate an empty pouch
• The unit must be connected to a supply voltage corresponding to the electrical rating
shown on the unit
• The socket-outlet shall be installed near the equipment and shall be easily accessible
• Do not use a carrier with this machine
• Ensure the machine is clear of pouches prior to starting the next pouch
• Clean the lamination rollers on a regular basis
• Maximum 9” document pouch 9” x 14½” on 9” Swingline GBC Fusion 1000L laminator
• Maximum 12” document pouch 12” x 16½” on 12” Swingline GBC Fusion 1000L laminator
• Failure to comply will result in damage and invalidate guarantee
m
m
m
m
English
