4
Required Radio Equipment
You will need a 4-channel transmitter, crystals, micro
receiver, and four sub-micro servos. You can choose to
purchase a complete radio system that includes all of these
items or if you are using an existing transmitter, just purchase
the other required equipment separately.
JRP14010** JR Sport 4-CH System, MD2 UL
(NOTE: Still need two additional servos)
Complete Radio System
Or Purchase Separately
JSP30610 6CH UL FM Receiver w/o Crystal,
Positive Shift (JR/AIRZ)
Or
JSP30615 6CH UL FM Receiver w/o Crystal,
Negative Shift (HRC/FUT)
JRPXFR** FM Receiver Crystal
EFLRS75 7.5 gram Sub-Micro Servo (4)
JSP98020 Y-Harness, Standard 6"
JSP98110 Servo Extension 6"
Important Information About Motor
Selection
We are recommending the E-flite™ Park 370 Brushless
Motor with 4100Kv (EFLM1000) or the Park 400 Outrunner
Brushless Motor, 920Kv.
The Park 370 Brushless Motor, 4100Kv provides more than
awsome power with a 1200–1320mAh 3-cell Li-Po battery
or park flyer power with a 2-cell Li-Po battery. Just use the
included 5.33:1 gearbox and 10x7 propeller.
It is extremely important to monitor gearbox wear and motor
temperature when using the 4100Kv motor. Lack of proper
throttle management using this motor and a 3-cell Li-Po
battery may result in damage to the motor, gearbox, ESC,
and battery. Adequate motor cooling is very important, so
make sure the motor is cooled properly in the cowl.
For a direct-drive Outrunner alternative, use the Park 400
Outrunner, 920Kv, which will also provide plenty of power
without worrying about gearboxes.
