15
I NSTALLATION
TAB TAB TAB 6 TAB TAB English TAB 3 TAB 2
Installing the TV on/off sensor
The TV on/off sensor enables the system to automatically
turn on the TV when another video source (DVD, cable/
satellite box, etc.) is selected. If you choose not to use the
sensor, you must turn on your TV separately.
For a larger TV, you may want a second person to help as
you follow the steps below:
N o t e : Front projectors with a separate screen may not
work with the sensor.
1. Plug the sensor cord connector into the media
center TV Sensor connector.
If you are using a SCART adapter, plug the sensor
directly into the pass-through connector provided
on the adapter (Figure 12 on page 17).
2. Temporarily position the TV on/off sensor on the
back of your TV (Figure 11).
N o t e : DO NOT attach the supplied mounting pad until
you have tested and activated the automatic feature as
explained below.
F i g u r e 1 1 TV on/off sensor positioned on the TV
Media center
TV sensor
