English 6
Getting Started
Parts and Accessories
Parts
Cooling Fan The cooling fan runs during all cooking modes. The fan can be heard when it is
running, and warm air may be felt as it is released from the oven vent. The fan may
also run after the oven is off.
Oven Vent The oven vent is located at the bottom of the unit. Warm air may be released from
the vent before, during and after cooking. It is normal to see steam escaping from
the vent, and condensation may collect in this area. This area may be warm when
the oven is in use. Do not block the vent, since it is important for air circulation.
Oven Bottom The oven bottom conceals the lower heating element. As a result the element is
protected from damage and spills.
Temp
Timer
Clock
Cook
Time
Light
Settings Off
Self Clean
Warm
Bake
Broil
Roast
Control Panel
Rack Position Guides
with 6 Rack Positions
Oven Bottom
Door Lock
Door Hinge
Oven Vent
Door Gasket
6
5
4
3
2
1
