BOXLIGHT CP-324i - Manual (Page 28)

28
Multifunctional settings
IMAGE Menu
Item Description
ASPECT
Using the buttons ▲/▼ switches the mode for aspect ratio.
At a RGB signal
4:3  16:9  NORMAL
At a video signal / no signal
4:3  16:9  SMALL
• The NORMAL mode keeps the original aspect ratio of the signal.
• At a HDTV signal of 1125i (1080i) or 750p (720p) of COMPONENT
VIDEO input, this item can't be selected.
• Performing the automatic adjustment initializes the aspect ratio
setting.
OVER SCAN
Using the buttons ▲/▼ adjusts the over-scan ratio.
Large (It reduces picture)  Small (It magnifies picture)
• This item can be selected only at a video signal.
• When this adjustment is too large, certain degradation may appear
at the frame area of the picture. In such a case, please adjust small.
V POSITION
Using the buttons ▲/▼ adjusts the vertical position.
Up  Down
H POSITION
Using the buttons ▲/▼ adjusts the horizontal position.
Left  Right
H PHASE
Using the buttons ▲/▼ adjusts the horizontal phase to eliminate
flicker.
Right  Left
• This item can be selected only at a RGB signal or a component
video signal.
With the IMAGE menu, items shown in the table below can
be performed.
Select an item using the cursor buttons ▲/▼ on the
projector or remote control, and press the cursor button ►
on the projector or remote control, or the ENTER button on
the remote control to progress. Then perform it referring to
the following table.
MENU [RGB] :SELECT
INPUT
SETUP
SCREEN
OPTION
EASY MENU ASPECT
OVER SCAN
V POSITION
H POSITION
H PHASE
H SIZE
AUTO ADJUST 4:3
95
25
142
16
1344
