Part No 891204 Form No F060911E 14
KVSP/TKVSP Owner’s Manual
KV600SP/KV600SPFB
PART NUMBER
QTY
KV650SPH/KV650SPHFB
PART NUMBER
QTY
TKV650SPH/TKV650SPHFB
PART NUMBER
QTY
46 SCREWCAP 1/4 - 20 x 5/8 HWH 890359 26 890359 26 890359 24
47 BOLT IDLER 3/8-16 X 1 1/2 800888 1 800888 1 800888 1
48 WASHER 1/4" SAE ZP 8172007 17 8172007 17 8172007 17
49 WASHER 5/16 FLATWASHER Z/P 8171003 19 8171003 19 8171003 19
50 SCREWCAP 5/16-18 X 1.75 ZP 8041031 8 8041031 8 8041031 8
51 NUT LOCK 5/16-18 8160002 8 8160002 8 8160002 8
52 NYLON INSERT LOCKNUT, 3/8-16 UNC 8160003 2 8160003 2 8160003 2
53 SCREWCAP 1/4-20 X 3/4" 8041004 2 8041004 2 8041004 2
54 NYLON INSERT LOCKNUT, 1/4-20 UNC 8160001 12 8160001 12 8160001 15
55 SCREWCAP #10-14 X 3/4" HWH ZP 891043 3 891043 3 891043 3
56 1/2-13 CAP NUT NP W/PATCH 890530 4 890530 4 890530 4
57 SCREWCAP 1/4-20 x 1 3/4 HCS ZP 8041009 1 8041009 1 8041009 1
58 SCREWCAP 1/4-20x2" 8041010 1 8041010 1 8041010 1
59 BELT 3L310 891026 1 891026 1 891026 1
60
61
NOZZLE TOP HALF KV 891002 1 891002 1 891002 1
62 NOZZLE BOTTOM HALF KV 891003 1 891003 1 891003 1
63 PLUG HOUSING KD LB 900146-01 1 900146-01 1 900146-01 1
64 SCREW PLASTIC 1/4-20 X 1 891039 8 891039 8 891039 8
65 WASHER 1.5 OD X .453 ID X .25 THK 440153 1 440153 1 440153 1
66
67
SPROCKET 65A26 26 TOOTH 890238 2 890238 2 890238 2
68
69
SCREW SELF TAP 1/4 x 0.75 900505 10 900505 10 900505 10
70 SCREW PLASTITE 1/4-20 X 3/4 HWH ZP 840082 3 840082 3 840082 3
71 SCREWCAP #10-24 X 5/8" - - - - 8059135 4
72 NYLON INSERT LOCKNUT 10-32 UNF ZINC - - - - 8164005 4
73 SCREW SOCKET HD 5/16-18 X 3/4 GR. 8 - - - - 890103 2
74 NUT KEPS 5/16-18 - - - - 890104 2
75 WASHER SHIM 0.875 ID X 0.060 - - - - 891065 2
76 WASHER SHIM 0.875 ID X 0.020 - - - - 891041 0-3
77 BLADE CHIPPER KD501 - - - - 890101 1
78 GUARD FLAPPER - - - - 890119 2
79 PLATE FLAPPER ENTRANCE - - - - 890127 2
80 LABEL SPARK ARRESTOR EN/SP - - 100252 1 100252 1
81 TAMPER CHIPPER - - - - 890229 1
82 LABEL DANGER CHIPPER - - - - 890152 1
83 CLIP 1/2" 350146 4 350146 4 350146 4
84 WOODRUFF KEY 1/8 X 1/2 510180 2 510180 2 510180 2
85 WASHER 1/2" FC 8171006 2 8171006 2 8171006 2
86 SPRING COMPRESSION 891072 1 891072 1 891072 1
87 LABEL DECAL KV/TKV 891046 1 891046 1 891047 1
88 SCREW SM 1/4 X 3/4 DRILL PT 510208 4 510208 4 510208 4
89 WASHER 1/4" SAE BLACK OXIDE 510193 4 510193 4 510193 4
91
92
CARRIAGE BOLT 1/4"-20 X 3/4" 8024021 4 8024021 4 8024021 4
93 SCREWCAP 1/4-20 X 1" HCS ZP 8041006 6 8041006 6 8041006 6
94 KV REINFORCEMENT NOZZLE BRACKET LFT 891062 1 891062 1 891062 1
95 KV REINFORCEMENT NOZZLE BRACKET RT 891064 1 891064 1 891064 1
96 KNOB 3/8-16 RED 891070 1 891070 1 891070 1
97 SPRING LEVER GZ 610429 1 610429 1 610429 1
98 TY WRAP 900407 4 900407 4 900407 4
99 NUT 1/4-20 ACORN 840071 2 840071 2 840071 2
100 RING CLASP FRONT BAG KV 891155 2 891155 2 891155 2
105 LABEL MADE IN U.S.A. 520116 1 520116 1 520116 1
