20
PROVIDEO CONVERTER AND VIDEO CONVERTER II
COMPOSITE (RCA phono jack)
Center Video Out
Outer Video Ground
S-VIDEO OUTPUT (4-pin mini-DIN female)
1 Ground
2 Ground
3 Luminance
4 Chrominance
RGBS OUTPUT (DB9 female)
1 Ground
3 Red
4 Green
5 Blue
8 Composite Sync
