Black Box 26720 - Manual (Page 2)

724-746-5500 blackbox.com
BLACK BOX
®
2 of 2 01/26/2010
#26720
» Extend your HDMI LCD or plasma display
connection up to 130 feet (39.6 m)
or 65 feet (19.8 m) on each side of this
digital signal booster.
» Corrects the signal degradation that occurs
in long HDMI cable runs.
» Eliminates pixilation, sparkles, and the loss
of video and audio that happens with HDMI
cable connections longer than 15 feet (4.5 m).
» Offers high-quality resolutions of 1080p
or UXGA.
» Provides up to 2.5 times the gain on the input
to compensate for cable loss.
» Easy plug-and-play installation.
» Backward compatible with DVI (with adapter).
» HDCP compliant.
Features
HDMI.
High-Definition Multimedia Interface (HDMI) is the first
digital interface to combine uncompressed high-definition
video, multichannel audio, and intelligent format and
command data in a single cable.
The HDMI standard was introduced in December
2002, and HDMI 1.2 was released in August 2005.
HDMI is supported by many leading consumer electronics
manufacturers as well as motion picture studios, and cable
and satellite operators.
The HDMI connector is compact and is somewhat similar
to a USB connector.
Use this serial interface to connect audio/video
equipment, such as DVD players, a set-top box, and A/V
receivers with an audio and/or video monitor, such as a digital
TV over a single cable. HDMI supports standard, enhanced,
and high-definition video. It has a bandwidth of up to 5
Gigabytes so it supports all HDTV standards and has
bandwidth to spare for future applications.
HDMI is backward compatible with DVI equipment
such as PCs, TVs, and other electronic devices using the DVI
standard. The DVI device simply ignores the extra data.
HDMI offers significant benefits over older analog A/V
connections. It provides superior video and audio clarity
because there is no signal loss from digital-to-analog
conversions. HDMI supports resolutions of 1920 x 1080p
and multiple audio formats from standard stereo to
multichannel surround sound. Plus it provides two-way
communication between the video source and the digital
TV, enabling simple, remote, point-and-click configurations.
HDMI is emerging as the connection standard for HDTV
and the consumer electronics market. Because HDMI
transmits all signals over one cable, it’s quite desirable
for home theater electronics and systems. It greatly simplifies
the installation of home entertainment systems by eliminating
the tangle of cables running behind the system. It’s also very
cost-effective because only one cable is needed.
technically speaking
Recognize any of these situations?
• You wait more than 30 minutes to get through
to a vendor’s tech support.
• The so-called “tech” can’t help you or gives
you the wrong answer.
• You don’t have a purchase order number
and the tech refuses to help you.
• It’s 9 p.m. and you need help, but your vendor’s
tech support line is closed.
According to a survey by Data Communi cations magazine, 90%
of network managers surveyed say that getting the technical support
they need is extremely important when choosing a vendor. But even
though network managers pay anywhere from 10 to 20% of their
overall purchase price for a basic service and support contract, the
technical support and service they receive falls far short of their
expectations—and certainly isn’t worth what they paid.
At Black Box, we guarantee the best value and the best support.
You can even consult our Technical Support Experts before you buy if
you need help selecting just the right component for your application.
Don’t waste time and money—call Black Box today.
Why Buy From Black Box?
Exceptional Value.
Exceptional Tech Support. Period.
T e c h S P e c S
Bandwidth (Maximum) — 1.65 Gbps
Compliance — Passthrough with HDCP 1.1 and 1.0
Distance (Maximum) — 130 ft. total (39.6 m), 65 ft. (19.8 m) on each side
with HDMI cables
Resolution — PC: VGA to UXGA 1920 x 1200;
HDTV: 480i to 1080p
CE Approval — Yes
Indicators — (1) Power LED
Power — 100–240-VAC, 50–60-Hz external adapter
Size — 2.8"H x 3"W x 1.3"D (7.1 x 7.6 x 3.3 cm)
Weight — 1.2 lb. (0.5 kg)
Item Code
HDMI Extender aC550a
