14
LED Indicators are located here:
ADJUSTING SOUND BAR SETTINGS
Press the Menu button and use the Up/Down Arrow buttons on the remote to access the different functions and acoustic settings
of the Sound Bar. Each function and setting will be displayed on the remote control’s LCD display. The LED Indicators will behave
differently with each function.
Function LED Behavior Description
Bluetooth Pairing (When searching for device)
Flash from Left to Right
and back continuously.
Press the Enter button on the remote. The Sound Bar will be discoverable for
15 minutes. You can now search for the Sound Bar (VIZIO S4221w) using your
Bluetooth Device. The sound bar will power down if no device is found.
Note: Set your Bluetooth device into pairing mode prior to the Sound Bar.
Bass Levels Two center LEDs
indicate Bass level 0.
Press the Next/Previous button to increase/decrease the bass level. The LED
indicators will move to the right with increasing levels and to the left with
decreasing levels.
Treble Levels Two center LEDs
indicate Treble level 0.
Press the Next/Previous button to increase/decrease the treble level. The
LED indicators will move to the right with increasing levels and to the left with
decreasing levels.
Dialog Levels Two center LEDs
indicate dialog is
centered.
Press the Next/Previous button to increase/decrease the presence of dialog
in the virtual center channel. The LED indicators will move to the right when
the dialog presence is increased and to the left when the dialog presence is
decreased.
Surround Levels Two center LEDs
indicate surround is
centered.
Press the Next/Previous button to increase/decrease the virtual surround sound
level. The LED indicators will move to the right with increasing levels and to the
left with decreasing levels.
Note: DTS TruSurround must be On to adjust the surround level.
BT Pair
Bass
Treble
Dialog
Surround
