Baja Marine Sportfish 250 - Manual (Page 56)

250 Sportfish ® 6.4
S
eCtion
6 • e
leCtriCal
S
ySteMS
R
Speed changes you. TM.
i
gnition
S
witCh
(fig. 6.4.1)
TO EngInE
RUn CIRCUIt
16 aWg
PURPlE/BlaCk
16 aWg
PURPlE/BlaCk
lanyaRD
stOP SWITCh
B
EXhaUSt
12 aWg RED
tOEXhaUSt
BREakER
fROM IgnITIOn
SWITCh ( I)
16 aWg
PURPlE/BlaCk
TO EngInE
B
RUn
Off
I
B S
staRt
16 aWg
yEl/RED
TO sTaRTER
SOlEnOID
ShIfTER'S nEUTRal
SafETy SWITCh
20a
12 VOlt DC
fROM EngInE
12 aWg
RED/BlaCk
a
note: This drawing contains information proprietary to Baja
Marine Corp. any unauthorized disclosure, use, or reproduction is
expressly prohibited, unless written permission of Baja
