Listening
With up to four inputs connected to the unit, you can decide which headphone
amplifier output you wish to use. To select the input(s) you wish to listen to, rotate the
selector switch to the appropriate point: AB means inputs A and B on the Left and
Right output respectively;, AA means input A on both Left and Right, etc. Plug your
headphones in and adjust the volume to an acceptable level.
DACS LTD, Stonehills, Shields Road, PELAW, Gateshead, Tyne and Wear NE10 0HW
Tel: +44 (0) 191 4382500 | Fax: +44 (0) 191 4382511 | www.dacs-audio.com | [email protected]
4 Earthing
The signal 0V is separate from the mains earth. This separation allows us to run
unbalanced with a large measure of immunity to hum problems, since the amplifier is
not referenced to or connected to any earth other than the signal source. The mains
earth is connected to the case of the device. If you wish to connect the signal earth to
the mains earth or a technical earth, this may be done by running a wire from the
earth tag. This connection should only be made by qualified personnel, if it is
necessary. If in doubt please call us.
5 Sensitivity Switches
On the rear panel, there are sensitivity switches for channels A&B and C&D.
This allows user selection of sensitivity as an operational control, rather than
having to be set with internal links.
7 Volume Control
The HEADPHONE VOLUME control adjusts the signal level going to the amplifier.
This control allows independent volume control of each output.
