FUNZIONE CANALI
CHANNEL FUNCTION
FONCTION DES CANAUX
KANALFUNKTIONEN
FUNCION DE LOS CANALES
I
GB
D
E
F
CHANNEL
EFFECT
IRIS
ZOOM
FOCUS
DIMMER
PAN
PAN FINE (only with option 16PT On)
TILT
TILT FINE (only with option 16PT On)
BLADE 1A
BLADE 1B
BLADE 2A
BLADE 2B
BLADE 3A
BLADE 3B
BLADE 4A
BLADE 4B
FRAMING ROTATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
STAGE PROFILE PLUS AE
I
i s
r
F o c u
P
n
a
D i m r
B l 1 A
T i l t
B l 1 B
B l 2 A
B l 2 B
B l 3 A
B l 3 B
B l 4 A
B l 4 B
R o F r
Z
m
o o
S
u t
h
P r F r
L i F r
X
c
F o
C
T
o l
R G 2
C y a n
M g n t
Y e l w
G
2
o b
G
1
o b
R G 1
CHANNEL
EFFECT
STOP/STROBE
COLOUR TEMPERATURE
PRISM/FROST
LINEAR FROST
EXTRA FOCUSING LENS
GOBO CHANGE 1
GOBO ROTATION 1
GOBO CHANGE 2
GOBO ROTATION 2
CYAN
MAGENTA
YELLOW
LAMP CONTROL (only with option LDmx On)
RESET (only with option RDmx)
GOBO 1 FINE (only with option 16Go On)
GOBO 2 FINE (only with option 16Go On)
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
