ALPHA PROFILE 700 & “ ST ”
On
Off
Display
MACRO EFFECTS
It lets you select the “Macro Effects” set up from the two available.
1) Press
F the current setting appears on the display.
2) Use the UP B and DOWN C keys to select one of the following settings:
Macro group size
It lets you set the number of projectors to be included in the macro mode
operation.
1) Press
F
2) Use the UP B , DOWN C , RIGHT keys to set the number of projectors
to be included in the “Macro Effect” operation.
3) Press F to confirm the selection or LEFT D to keep the current setting.
Macro fixture Id
It lets you attribute an ID address to the projector for the phase displacement
for the scene’s starting time in Macro mode.
1) Press
F
2) Use the UP B and DOWN C keys to select one of the following settings:
Fixed to X. (to assign to all the projectors to be included in the Macro
operation).
Auto by DMX Address: According to the DMX address, it automatically
detects the starting sequence of the scene in the Macro mode (to assign
to all the projectors to be included in the Macro operation).
3) Press F to confirm the selection or LEFT D to keep the current setting.
LAMP DIMMING
This lets you select the lamp “dimmer” mode, selecting one of the two
available modes:
• Electronic: Default setting, the lamp is electronically “dimmed” from
100% to 80% and mechanically for the rest of the range. Visually, the
Dimmer curve is high performance but a slight flicker could be noted in
some Dimmer channel positions.
• Mechanic: The lamp is totally mechanically dimmed, only when the
Dimmer is fully closed does the lamp operate at half power. No lamp
flicker is visible when this option is selected.
POWER MODE
Allows you to select a Power Mode from the three available.
1) Press
F - the current settings appear on the display.
2) Use the UP B and DOWN C keys to select one of the following
settings:
- 4-700W Full fan speed: Lamp can change from full-power (700W) to
half-power (400W) using the LAMP CONTROL channel. Fans always
work at Full speed.
- 400W Low fan speed: Lamp constantly works in half-power mode
(400W) while the Fan always works at Low speed. With LAMP
CONTROL channel you can only switch the lamp ON and OFF.
- 4-700W Auto fan speed: Lamp can change from full-power (700W) to
half-power (400W) using the LAMP CONTROL channel. Automatically
the fans switch from Full speed to Low speed respectively.
3) Press F to confirm the selection or LEFT D to keep current setting.
DISPLAY
Used for automatically reduce brightness on the display after about 30
seconds in idle.
1) Press
F - the current settings appear on the display (On or Off).
2) Use the UP B and DOWN C keys to enable (On) or disable (Off) the
decreasing of display brightness.
3) Press F to confirm the selection or LEFT D to keep current settings.
SETTING
Used to save 3 different settings of the items in the options menu and
relative submenus.
1) Press
F - “Default preset” appears on the display.
2) Use the UP B and DOWN C keys to select one of the following
configurations:
- Default preset (*)
- User preset 1
- User preset 2
- User Preset 3
3) Press F - “Load preset X” appears on the display.
Power Mode
4-700W
Full fan speed
400W
Low fan speed
4-700W
Auto fan speed
Macro
Effects
Macro fixture Id
Macro group
size
Lamp
dimming
Mechanic
Electronic
Load
Preset 1
Save To
Preset 1
User
Preset 1
Reset To
Dafault
Go Back
