On-screen display (OSD)
25
Geometry menu
This menu is available only when an analog video signal is selected.
Function Description
Auto adjust-
ment Selects the Auto adjustment submenu, which con-
tains the following functions:
Auto Adjust performs the Auto Geometry, Clock
and Phase functions.
Auto Color performs the Auto Offset and Gain
functions.
Clock Manually adjust the internal clock frequency.
Increasing this value makes the image wider.
Decreasing this value makes the image smaller.
Phase Manually adjusts the internal clock phase. When
not adjusted correctly, vertical bands with alter-
nate intensity appear in the image.
H Position Manually adjust the image horizontal position
V Position Manually adjust the image vertical position
