-6-
Functional Description and Specifications
Disconnect the plug from the power source before making any
assembly, adjustments or changing accessories. Such preventive safety
measures reduce the risk of starting the tool accidentally.
!
WARNING
Hammer Drills
5
6
7
8
9
12
13
14
15
16
17
18
19
20
“LOCK-ON”
BUTTON
AIR
VENTS
MODE
SELECTOR
SWITCH
WING
KNOB
(B)
CHUCK
AUXILIARY
HANDLE
DEPTH
GAUGE
WING
KNOB (A)
TRIGGER
REVERSING
SWITCH
LEVER
GEAR
CHANGE
SELECTION
LEVER
FIG. 1
COLLAR
MOUNT
SPINDLE
FLATS
Model number
1194VSR
1194AVSR
No load speed 1
n
0
0-1,000/min
n
0
0-1,000/min
No load speed 2
n
0
0-3,000/min
n
0
0-2,600/min
Maximum capacities
Chuck capacity
1/2"
1/2"
Material
1 low
2 high
1 low
2 high
Concrete
3/4"
3/8"
3/4"
3/8"
Aluminum
5/8"
3/8"
5/8"
3/8"
Steel
1/2"
1/4"
1/2"
1/4"
NOTE: For tool specifications refer to the nameplate on your tool.
