6
1a) Remove the parts from their packaging and familiarize yourself
with them. (see pg. 2)
1b) The BSA ® BOW Mount is meant to be attached to your bow in
place of your existing sights.
NOTE: Before beginning the installation process, your existing
sights must be removed. The sight screw holes in the riser of your
bow will be used to attach your BSA® BOW Mount .
Tech Tip #1: To make sighting in easier, mark on the inside of the
riser window your most commonly used pin location. This will be
useful later in quickly locating the red dot.
Tech Tip #2: The weaver style rail is attached to the mounting plate
so it can be used with a right hand bow. For a left hand bow, the rail
must be removed and placed on the opposite side of the mounting
plate.
1c) Hold the bow so that it is possible for you to sight the drawstring
passing through the center of your bows limbs and the center of
your arrow rest. Keeping this orientation, lay the red dot sight
mounting bracket against the outside of the riser. With the red dot
sight extending inside, approximately over the arrow rest.
1. ASSEMBLY
