SET UP

water line to sink

¼” poly water line
to coffee maker

cold water
valve

angle stop
valve
adaptor

Option 1: Cold Water Tap

water line

to ice maker

¼” poly water line

to coffee maker

Option 2: Ice Maker Line

cold water line

• connection to water supply (supplied)

• remove water line from valve to facet

• add valve

• reconnect facet line to tee hardware

• connect new ¼” poly line to valve connection

• Valve connection included

• cut existing line from house interior wall where water line starts and runs

to refrigerator. Do Not cut line located on the refrigerator. If line is not ¼”,

then refer to note below for additional information on obtaining parts to

connect. You may also contact us directly at [email protected]

• add valve
• connect new ¼” poly line to tee

PLEASE NOTE:

If you have a ¼” compression waterline connection and you are not able to simply cut and use the enclosed T part, you can

use the supplied 3/8” John Guest Valve with adapter parts (not supplied). Basically by adding the following parts to the 3/8”

John Guest valve it will allow you to connect to a braided style ¼” compression line that is connecting to your refrigerator. The

following parts can be found at most home improvement big box stores.

1. Watts: LFA-157 - Compression adapter (3/8” OD x 1/4” female OD)

2. Watts: LFA-109 - Ander-lign Compression Union (3/8” OD by 1/4” OD)

3. Anderson-Barrows 12” Filter supply line 1/4’ compression to 1/4” compression

3. Connect water line to water source.

A. Water source options are typically the cold water tap under the sink or the water line connecting to the refrigerator ice

maker.

DO NOT connect directly to ice maker line located on refrigerator.

B. If connecting to refrigerator supply Brew Express provides a ¼” T to connect to the ¼” line. Sometimes this supply line may

be a compression braided line. If so, it may require additional parts (not supplied). Please contact Brew Express for advice,

or additional notes below Option #2.

C. Do not connect to dishwasher line.

NOTE – shut off water sources before removing or alternating existing lines.
