Specifications
Part No.: F1DL102U
PCs Supported: 2
Monitors Supported: VGA, SVGA, MultiSync
Max. Resolution: 2048x1536@65Hz
Keyboard Input: USB
Mouse Input: USB
Audio/Mic Input: 3.5mm jack
VGA Port: 15-pin HDDB type
LED Indicators: 2
Enclosure: Plastic
Dimensions: 27.5 (H) x 82 (W) x 81.25mm (D)
Weight: 1.2 lbs.
Operating Temp: 32° to 104° F (0° to 40° C)
Storage Temp: -4° to 140° F (-20° to 60° C)
Humidity: 0-80% RH, non-condensing
Warranty: 3 years
NOTE: Specifications are subject to change without notice.
6 5
OVERVIEW OVERVIEW
Push button
with LEDs
The 2-Port KVM Switch with Audio Support and Built-In Cabling:
Console USB Port
Unit Display Diagram
Built-In Cables
Console USB Port
Console VGA
Monitor Port
Console
Speaker Jack
Console
Mic Jack
