9
Operating Instructions
This charger can charge up to 8 batteries independently as follows:
- the channels 1-2-3-4 (left and right side of the charger) are
independent. The charge is managed simultaneously within
each channel.
- the additional four channels 5-6-7-8 are paired with the first four
channels in respective order and the charge is handled
sequentially within each pair (1-5, 2-6,3-7,4-8): first available/
first charged
How to proceed:
-
Plug the AC power cord provided into the charger AC input
- Plug and switch on the AC mains supply
- Insert a battery inside any one of the four V-plate adapters as
shown (see picture)
- Observe the LED. In addition, the charge status may be read in
20% steps through the BLUESHAPE battery LED array.
- Leave the battery to charge for the appropriate time (see table
on page 6)
- Remove the battery when the LED becomes steady green as
shown (see picture on next page)
In the case when you want to charge 2 or more batteries, insert the
additional batteries into the available V-plate adapters.
CVS8X
BV070
BV100
BV140
BV175
BV210
Insert in the direction of the arrow
