1 Your refrigerator
1- Ice cube tray
2- Freezer shelf
3- Interior light
4- Thermostat knob
5- Fridge compartment shelves
6- Defrost water collection channel-
Drain tube
7-
Crisper cover
8- Salad crisper
9- Crisper
9- Adjustable front feet
10- Dairy compartment
11- Door shelves
12- Egg tray
13- Bottle shelf
A- Freezer compartment
B- Fridge compartment
* OPTIONAL
