ToughPAR RGBAW Manual Rev. A Copyright (c) 2011 Blizzard Lighting, LLC
DMX Values In-Depth (9-Channel Mode)
Channel Value What It Does
1 000 <--> 255 Dimmer (0% <--> 100%)
2 000 <--> 255 Red Intensity (0% <--> 100%)
3 000 <--> 255 Green Intensity (0% <--> 100%)
4 000 <--> 255 Blue Intensity (0% <--> 100%)
5 000 <--> 255 Amber Intensity (0% <--> 100%)
6 000 <--> 255 White Intensity (0% <--> 100%)
7
000 <--> 014
000 <--> 255
Strobe
Strobe Off
Strobe (Slow <--> Fast)
8
000 <--> 031
032 <--> 063
064 <--> 095
096 <--> 127
128 <--> 159
160 <--> 191
192 <--> 249
250 <--> 255
Fade, Color Change, Sound Active
No Function
Fade In (Ch. 9 Controls Speed)
Fade Out (Ch. 9 Controls Speed)
Fade In / Fade Out (Ch. 9 Controls Speed)
Multicolor Fade (Ch. 9 Controls Speed)
5 Color Jump (Ch. 9 Controls Speed)
Multicolor Jump (Ch. 9 Controls Speed)
Sound Active
9
0 <--> 255
Fade Speed
Fade Speed (Slow <--> Fast)
DMX Values In-Depth (4/5-Channel Mode)
Ch. Value What It Does (5
Ch.)
What It Does (4 Ch.)
1 000 <--> 255 Red Intensity Red Intensity
2 000 <--> 255 Green Intensity Amber Intensity
3 000 <--> 255 Blue Intensity White Intensity
4 000 <--> 255 Amber Intensity Dimmer (0-100%)
5 000 <--> 255 White Intensity ---
