Torrent 90 Manual Rev. C Copyright (c) 2012 Blizzard Lighting, LLC
2. MEET THE TORRENT 90™ SPOT
CONTROL FEATURES
• 15-channel DMX LED moving yoke
• Pan: 540º/630º/ Tilt: 270º
• Color wheel: 7 colors + white
• Rainbow color spin at variable speeds
• 7 interchangeable, rotating slot-n-lock gobos + open (5 glass installed,
Gobo Wheel #1)
• 9 static gobos (Gobo Wheel #2)
• Ability to layer gobos for multicolor/multi-textured effects.
• Gobo wheel spin at variable speeds
• Gobo indexing
• 3-facet rotating prism
• Variable 3-mode electronic strobe
• Variable electronic dimmer (0 – 100%)
• Remote focus via DMX (2m~infinity)
• Variable mechanical iris with burst and linear control
• Remote fixture reset
• User-selectable solid or split colors and gobos
• Multiple built-in automated & sound activated programs
• User-programmable built-in programs
• PowerCON® compatible power in/out connectors
ADDITIONAL FEATURES
• Lux: 47,900 @ 1m, 8,232 @ 2.5m
• Gobo size: 27.9mm outside, 23mm image, 1.2mm max thickness
• Beam Angle: 15º (20º optional)
• Light source: 90W White, US-Made Luminus CBM-360 LED, 50,000 hrs
DMX Quick Reference
Channel What It Does
1 Pan
2 Pan Fine (16-Bit)
3 Tilt
4 Tilt Fine (16-Bit)
5 Color
6 Gobo Wheel #1
7 Gobo Rotation
8 Gobo Wheel #2
9 Shutter/Strobe
10 Dimmer
11 Focus
12 Prism
13 Iris
14 Pan/Tilt Speed
15 Reset/Special Functions
