Blizzard Lighting V12 The Puck (REV A) - Manual (Page 21)

Page 21
The Puck™ V12 Manual Rev. A © 2013 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Length 8.25 inches (210 mm)
Width 3.875 inches (98.43 mm)
Height 8.5 inches (215.9 mm)
Weight 4.2 lbs (1.92 kg)
Power
Operating Voltage 100-240VAC, 50-60 Hertz
Power Consumption 120W
Light Source
LED 12* 15-watt 5-in-1 LEDs, 100,000 hours
Optical
Beam Angle 25°, Field Angle: 29°
Thermal
Max. Operating Temp. 104 degrees F (40 degrees C) ambient
Control
Protocol USITT DMX-512
DMX Channels 3/4/5/6/7/ 12-Channels
Input 3-pin XLR Male
Output 3-pin XLR Female
Other Operating
Modes Standalone, Master/Slave, Color Preset
Other Information
No word in the English language rhymes with, orange, silver or purple.
Warranty
2-year limited warranty, does not cover mal-
function caused by damage to LED’s.
