Blizzard Lighting Beam Torrent 90 (Rev A) - Manual (Page 13)

Page 13
Torrent 90 Beam Manual Rev. A Copyright (c) 2011 Blizzard Lighting, LLC
DMX Channel Values
Channel Channel Value Does...
1 000 <-> 255 Pan
2 000 <-> 255 Pan Fine (16-Bit Pan)
3 000 <-> 255 Tilt
4 000 <-> 255 Tilt Fine (16-Bit Tilt)
5
000 <-> 019
020 <-> 039
040 <-> 059
060 <-> 079
080 <-> 099
100 <-> 127
128 <-> 189
190 <-> 193
194 <-> 255
Color
Open
Color 1
Color 2
Color 3
Color 4
Color 5
Color Wheel Scroll (Clockwise, Fast <-> Slow)
Stop
Color Wheel Scroll (Counter-Clockwise, Slow <-> Fast)
6
000 <-> 009
010 <-> 019
020 <-> 029
030 <-> 039
040 <-> 049
050 <-> 059
060 <-> 069
070 <-> 079
080 <-> 099
100 <-> 119
120 <-> 139
140 <-> 159
160 <-> 179
180 <-> 199
200 <-> 219
220 <-> 255
Gobo Wheel #1
Open
Gobo 1
Gobo 2
Gobo 3
Gobo 4
Gobo 5
Gobo 6
Gobo 7
Gobo Shake 1
Gobo Shake 2
Gobo Shake 3
Gobo Shake 4
Gobo Shake 5
Gobo Shake 6
Gobo Shake 7
Gobo Wheel Spin (Slow <-> Fast)
7
000 <-> 031
032 <-> 063
064 <-> 095
096 <-> 127
128 <-> 159
160 <-> 191
192 <-> 223
224 <-> 255
Strobe
Closed
Open
Strobe (Slow <-> Fast)
Open
Pulse Strobe (Slow <-> Fast)
Open
Random Strobe (Slow <-> Fast)
Open
8
000 <-> 255
Dimmer
0 <-> 100%
9 000 <-> 255
Focus
Near <-> Far
12
000 <-> 005
006 <-> 127
128 <-> 189
190 <-> 193
194 <-> 255
Prism
Prism Out
Prism In
Prism Rotation Clockwise (Fast <-> Slow)
Stop
Prism Rotation Counter-Clockwise (Slow <-> Fast)
13 000 <-> 199
200 <-> 255
Frost
No Frost
Frost
