Blizzard Lighting RGBAW StormChaser Skywire (Rev A) User Manual
Page 6
Page 6
StormChaser Skywire Manual Rev. A
Copyright © 2013 Blizzard Lighting, LLC
Figure 1: The StormChaser™ Skywire RGBAW Pin-Up Picture
High Power
LED’s
Anodized Aluminum
Enclosure
Mounting Bracket
& Adjustment
Screw
Figure 2: The Rear Connections
AC
Power In
Main/Wireless
Power Switches
DMX In/Out
Sound Sensitivity
Wireless Ch. Selector
Button & LED Indicator
Antenna Connection
Battery Power
Level Indicator
LED Menu Mic
