Page 6 – Blizzard Lighting Infiniwhite RokBox (Rev A) User Manual
Page 6
Page 6
RokBox Infiniwhite Manual Rev. A
© 2014 Blizzard Lighting, LLC
Figure 1: The RokBox™ Infiniwhite Pin-Up Picture
High Power 3-in-1
ACW LEDs
Heavy-Duty Cast
Aluminum Enclosure
Dual Mounting Yokes &
Adjustment/Locking Knobs
Figure 2: The Rear Connections
AC Power Out
DMX In
DMX Out
Menu Buttons
AC Power In
LED Display
