Page 6 – Blizzard Lighting RGBAW RokBox 5 (Rev A) User Manual
Page 6
Page 6
RokBox 5 RGBAW Manual Rev. A
© 2013 Blizzard Lighting, LLC
Figure 1: The RokBox™ 5 RGBAW Pin-Up Picture
High Power 5-in-1
RGBAW LEDs
Heavy-Duty Cast
Aluminum Enclosure
Dual Mounting Yokes &
Adjustment/Locking Knobs
Figure 2: The Rear Connections
AC Power Out
DMX In
DMX Out
Menu Buttons
AC Power In
LED Display
