HotBox 5 RGBAW/RGBVW Manual Rev. A
Copyright © 2013 Blizzard Lighting, LLC
Figure 1: The HotBox™ 5 Pin-Up Picture
High Power 5-in-1
15-watt LEDs
Heavy-Duty Cast
Aluminum Enclosure
Dual Mounting Yokes &
Adjustment/Locking Knobs
Figure 2: The Rear Connections
AC Power Out
DMX In
DMX Out
Menu Buttons
AC Power In
LED Display
