Blizzard Lighting RGBW Q-Stick (Rev B) User Manual
Page 6
Page 6
Q-Stick™ RGBW Manual Rev. B
Copyright (c) 2012 Blizzard Lighting, LLC
Figure 1: The Q-Stick™ Pin-Up Picture
High Power
4-in-1 LEDs
Sturdy metal enclosure
Mounting Yoke & Adjustment/
Locking Knobs
Figure 2: The Rear Connections
3-Pin & 5-Pin DMX In
Fan Guard
POWER In
3-Pin & 5-Pin DMX Out
POWER Out
LED Control Panel
