The Puck Pro Zoom Manual Rev. B Copyright (c) 2012 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Length 11.5 inches (290.95 mm)
Width 11.25 inches (284.63 mm)
Weight 5.8 pounds (2.63 kg)
Power
Operating Voltage 90-240VAC, 50-60 Hertz
Power Factor 0.65
Power Consumption 85W
Current 1.1A (.1A inrush)
Light Source
LED 14* 10-watt Quad-Color LEDs, 100,000 hours
Optical
Beam Angle 25°-45°
Luminous Intensity 8,600 LUX @ 1m, 2,900 LUX @ 2m
Thermal
Max. Operating Temp. 104 degrees F (40 degrees C) ambient
Control
Protocol USITT DMX-512
DMX Channels 5/6/7/8/13 Channels
Input 3-pin XLR Male
Output 3-pin XLR Female
Other Operating
Modes Standalone, Master/Slave, Color Preset
Coolness Factor
Leventy Billion Percent
Warranty
2-year limited warranty, does not cover malfunction
caused by damage to LED’s.
DISCLAIMER:
The power connector fitted to the fixture and fixture cord are designed for compatibility
with products manufactured by Neutrik AG, Neutrik USA and their related entities,
however they are not manufactured by, affiliated with or endorsed by Neutrik
AG, Neutrik USA, or any related entity. Neutrik® and powerCON® are registered
trademarks of Neutrik AG.
