NorthStar Quantum Pro Manual Rev. B Copyright (c) 2011-12 Blizzard Lighting, LLC
2. MEET THE NORTHSTAR QUANTUM™ PRO
CONTROL FEATURES
• User Defi nable DMX Personalities, 12, 14 or 38-channel DMX LED moving yoke
• Pan: 540º/630º Tilt: 270º
• Full RGBW Color Mixing or
• Stunning 6-segment RGBW color mixing with chase/graphics capabilities
• Pan/Tilt Invert
• Variable 0-18FPS electronic strobe
• Variable electronic dimmer (0 – 100%)
• Remote fi xture reset
• Multiple built-in color macros
• Multiple built-in automated programs
• User-programmable manual mode & programs
• 5 preset white outputs - 2700K, 3200K, 4200K, 5600K, 8000K
ADDITIONAL FEATURES
• Lux: 56,500 @ 1m, 10,000 @ 5m
• Beam Angle: 25º
• Light source: 36x 10-Watt (4*2.5w) CREE® RGBW “Quad-Color” LEDs,
>50,000 hour life expectancy
• Industry-Standard Neutrik® POWERCON® Power In/Out
• Quarter-Turn “OMEGA” clamp bracket
• Compact and lightweight
DMX Quick Reference
Channel What It Does
1 Pan
2 Pan Fine (16-Bit)
3 Tilt
4 Tilt Fine (16-Bit)
5 Strobe
6 Dimmer
7 Red (Entire Fixture)
8 Green (Entire Fixture)
9 Blue (Entire Fixture)
10 White (Entire Fixture)
11 Pan/Tilt Speed
12 Color Macros
13 Segment Control Mode
14 Functions
14-38 Individual Segment Control
