NorthStar Quantum Pro Manual Rev. A Copyright (c) 2011 Blizzard Lighting, LLC
2. MEET THE NORTHSTAR QUANTUM™ PRO
CONTROL FEATURES
15 or 39-channel DMX LED moving yoke •
Pan: 540º/630º Tilt: 270º •
Full RGBW Color Mixing or •
Stunning 6-segment RGBW color mixing with chase/graphics capabilities •
Pan/Tilt Invert •
Variable 0-18FPS electronic strobe •
Variable electronic dimmer (0 – 100%) •
Remote fi xture reset •
Multiple built-in color macros •
Multiple built-in automated programs •
User-programmable manual mode •
ADDITIONAL FEATURES
Lux: 56,500 @ 1m, 10,000 @ 5m •
Beam Angle: 25º •
Light source: 36x 10-Watt (4*2.5w) CREE® RGBW “Quad-Color” LEDs, •
>50,000 hour life expectancy
Industry-Standard Neutrik® POWERCON® Power Connection •
Quarter-Turn “OMEGA” clamp bracket •
Compact and lightweight •
DMX Quick Reference
Channel What It Does
1 Pan
2 Pan Fine (16-Bit)
3 Tilt
4 Tilt Fine (16-Bit)
5 Dimmer
6 Strobe
7 Red (Entire Fixture)
8 Green (Entire Fixture)
9 Blue (Entire Fixture)
10 White (Entire Fixture)
11 Pan/Tilt Speed
12 Color Macros
13 Segment Control Mode
14 Built-In Programs
15 Reset
16-39 Individual Segment Control
