HotStik™ 5 COB User Manual - Rev. A (c) 2014 Blizzard Lighting, LLC
Tech Specs!
Weight & Dimensions
Length 42.7 inches (1084 mm)
Width 4.92 inches (125 mm)
Height 5.43 inches (138 mm)
Weight 21.1 lbs (10 kg)
Power
Operating Voltage 110V-240VAC, 50-60 Hertz
Power Consumption 236W, 1.95a, pf:.99
Light Source
LED 12x 25w Tianxin high power RGBAW COB 5-in-1 LEDs
Optical
Beam Angle 80 degrees
Luminous Intensity Meters / Lux Red Green Blue Amber White RGBAW
1m 1,950 2,000 2,120 1,000 2,200 8,610
2m 750 750 780 380 800 3,000
Thermal
Max. Operating Temp. 104 degrees F (40 degrees C) ambient
Control
Protocol USITT DMX-512
DMX Channels 5/9 (User Selectable)
Input 3-pin XLR Male
Output 3-pin XLR Female
Operating Modes Standalone, Master/Slave
Other Information
A lot of people are afraid of heights. Not me, I’m afraid of widths.
Warranty
2-year limited warranty, does not cover malfunction caused by
damage to LED’s.
DISCLAIMER:
The power connector fitted to the fixture and fixture cord are designed for compatibility
with products manufactured by Neutrik AG, Neutrik USA and their related entities, howev-
er they are not manufactured by, affiliated with or endorsed by Neutrik AG, Neutrik USA,
or any related entity. Neutrik® and powerCON® are registered trademarks of Neutrik AG.
