HotBox™ EXA Manual Rev. A
© 2013 Blizzard Lighting, LLC
Figure 1: The HotBox™ EXA Pin-Up Picture
Figure 2: The Rear Connections
AC Power Out
DMX In
DMX Out
Menu Buttons
AC Power In
LED Display
High Power 15w 6-in-1
RGBAW+UV LEDs
Heavy-Duty Cast
Aluminum Enclosure
Dual Mounting Yokes &
Adjustment/Locking Knobs
