25
Step 12
Remove the plastic cap on gas
supply manifold and attach rubber
gas hose to gas supply manifold.
Hand tighten first, then use
supplied wrench to turn brass nut
an additional 1/8 turn.
Important: Do not overtighten.
This could damage
brass fitting.
Warning: Never use your grill
without leak testing all
gas connections and
hoses. See the section
on “Leak Testing” in this
manual for proper
procedures. (See page 7)
Step 13
Attach side burner igniter lead to
the electrode as illustrated.
Step 14
Attach side table assembly to grill
body assembly by inserting four
M6 X 20mm bolts halfway into the
screw holes of the grill body
assembly. Then slide side table
assembly onto bolts and secure all
four bolts.
Gas Hose
Side Burner Igniter
Lead
Electrode
Side Table
Screw Holes
Brass Nut
