Page 12
Introduction
8
Bottom Side
Connector Panel
Refer to page
for more information on making connections to various equipment.
Lamp door
Front adjuster foot
Rear adjuster foot
Rear adjuster foot
RGB signal input
(PC/ YPbPr/ YCbCr)
RGB signal output
AC inlet
S-Video Mini DIM
USB connector
Audio jack
Video RCA jack
IR remote sensor
